SC44VM
Electrically driven pump 4" for sewage, contaminated water and bentonite.
Request your quote Download the brochureThe SC44VM is an electrically driven pump group, is self-priming and is equipped with a 6" male Perrot quick coupling and a 4" male Perrot quick coupling. The pump is suitable for sewage, muddy water and bentonite.
Specifications
- Type: Pioneer SC44VM
- Applications: sewage, contaminated water, bentonite, …
- Max. pressure: 34 mwc
- Max. capacity: 245 m³/h
- Motor: 3 x 400 V, 60 Hz
- Power output: 30 kW Inom = 56,2 A
- Pump: max. 18 kW at 50Hz, max. 26 kW at 60Hz (clear water)
- Free impeller passage: 85 mm, vortex impeller
- Weight: 1.260 kg
- L x W x H: 2.220 x 1.060 x 1.600 mm
- Coupling: suction side : Perrot quick coupling 6" male, discharge side : Perrot quick couplings 4" male
- Centrifugal pump: dry self-priming centrifugal pump, switchable vacuum pumping system
- Charasteristics: Standard no control, 3 cables 20 m with free cable end
- Connection: main pump 4x16mm², PTC resistor 3x2,5mm² and vacuum pump MP50 4x2,5mm²
- Optional: control possible through optional mobile frequency controller
- Equipment: stackable subframe, with forklift pockets and lifting eye
