BQY200
Diesel-driven pump 8", sound attenuated, for sewage, sludge and slurry.
Request your quote Download the brochureThe BQY200 is a diesel-driven pump group suitable for sewage water, muddy water and sludge. The pump is mounted on a skid, is fully enclosed, is dry self-priming, and is equipped with 8" male Triflex quick couplings.
If desired, an external diesel tank can be rented.
Specifications
- Type: SPP Pumps, BQY200
- Applications: sewage, sludge, slurry, …
- Max. pressure: 33,5 mwc
- Max. capacity: 530 m³/h
- Engine: Yanmar stage III 4TNV88
- Power output: 28 kW at 2.000 rpm
- Free impeller passage: 75 x 90 mm
- Starting system: 12 V electrical start
- Weight: 2.130 kg
- Tankage: 325 liters
- Consumption: 6,1 liters/hour at maximum capacity
- Autonomy: 50 h (at maximum capacity)
- L x W x H: 2.326 x 1.244 x 1.740 mm
- Coupling: suction and discharge : Triflex quick couplings 8" male
- Characteristics: automatic dry self priming, indefinite dry-running possible
- Version: on skid, sound attenuated, fully bunded canopy 69 dB at 7 m
- Level detection: float switches for automatic working
- LEL detection: socket for LEL detection
- Equipment: spark-arrestor, emergency switch, battery switch, lifting eye, forklift pockets
- Connection fuel tank: threeway valve for the connection of an external fuel tank
