8NHG–TAD1375VE
High-pressure diesel-driven pump 14", sound attenuated, for clear and polluted water.
Request your quote Download the brochureThe 8NHG is a high-pressure diesel-driven pump group suitable for lances, fire extinguishing applications, clear and contaminated water. The pump is dry self-priming and is fitted with a DIN flange DN350 PN10 and a DIN flange DN200 PN16.
If desired, an external diesel tank can be rented.
Specifications
- Type: BBA BA-C200S8
- Applications: jetting, fire fighting-like applications, clear and polluted water, …
- Max. pressure: 130 mwc
- Max. capacity: 1.250 m³/h
- Engine: Volvo TAD1375VE
- Power output: 395 kW at 1.850 rpm
- Free impeller passage: 62 mm
- Starting system: 24 V electric start
- Weight: 10.000 kg (dry)
- Tankage: 300 liters Adblue / 300 liters fuel
- Consumption: 99 liters/hour at maximum capacity
- Autonomy: 2,5 h at maximum capacity
- L x W x H: 5.830 x 2.306 x 2.550 mm
- Coupling: suction : DIN flange DN350 PN10, discharge : DIN flange DN200 PN16
- Characteristics: automatic dry self priming, dry-running possible
- Version: on skid, sound attenuated fully bunded canopy ca. 82 dB at 10 m
- Level detection: automatic level adjustment with 2 floats or probe 4-20 mA
- Equipment: spark-arrestor, Chalwyn valve, master switch, 4 x lifting eye, forklift pockets
- Connection fuel tank: threeway valve for the connection of an external fuel tank
