80CH
High-pressure diesel-driven pump 6", sound attenuated, for clear to polluted water.
Request your quote Download the brochureThe 80CH is a high-pressure diesel-driven pump group, is dry self-priming, and is equipped with a 6" male Perrot quick coupling and a DIN flange DN80 PN16. The pump is suitable for lances, fire extinguishing applications, clear and contaminated water.
If desired, an external diesel tank can be rented.
Specifications
- Type: Pioneer PP63C17M2-E0311
- Applications: fluidization, fire fighting-like applications, clear to polluted water, …
- Max. pressure: 130 mwc
- Max. capacity: 215 m³/h
- Engine: JCB 444TCAE
- Power output: 120 kW at 2.000 rpm
- Free impeller passage: 20 mm
- Starting system: 12 V electrical start
- Weight: 3.425 kg (full tank)
- Tankage: 695 liters
- Consumption: 23,3 liters/hour at maximum capacity
- Autonomy: 30 h at maximum capacity
- L x W x H: 2.950 x 1.450 x 2.110 mm
- Coupling: suction : Perrot quick coupling 6" male, discharge : DIN flange DN80 PN16
- Characteristics: automatic dry self impriming, dry-running possible
- Version: on skid, sound attenuated, fully bunded canopy
- Level detection: automatic level adjustment by 2 float switches
- Equipment: spark-arrestor, master switch, central lifting eye, forklift pockets
- Connection fuel tank: threeway valve for the connection of an external fuel tank
