K100H/F32
High-pressure diesel-driven pump 4", sound attenuated, for slightly polluted water.
Request your quote Download the brochureThe K100H/F32 is a high-pressure diesel-driven pump group, not self-priming. The pump is suitable for lances, fire extinguishing applications and slightly contaminated water, and is equipped with a 4" male Perrot quick coupling and a DIN flange DN100 PN16.
Specifications
- Type: F33K100H/3E
- Applications: fluidization, fire fighting-like applications, slightly polluted water
- Max. pressure: 142 mwc
- Max. capacity: 144 m³/h
- Motor: Iveco F32
- Power output: 52 kW at 1.800 rpm
- Free impeller passage: 8 mm
- Starting system: 12 V electrical start
- Weight: 2.430 kg (full tank)
- Tankage: 1.000 liters
- Consumption: 12,5 liters/hour at maximum capacity
- Autonomy: ca. 80 h
- L x W x H: 2.500 x 1.150 x 1.800 mm
- Coupling: suction: Perrot quick coupling 4" male, discharge: DIN flange DN100 PN16 with gate valve
- Characteristics: not self priming (to be filled with internal tank and venturi system)
- Version: fully bunded canopy, sound attenuated
- Equipement: adjustable speed, pump security
